The Figure 01 changed the trajectory of humanoid robotics when it debuted in 2023. Built by Figure AI — a startup that raised over $675 million from Microsoft, NVIDIA, OpenAI, and Jeff Bezos — the Figure 01 was the company's proof-of-concept humanoid designed for real-world commercial labor. In this Figure 01 review, we break down its full specifications, real-world capabilities, OpenAI-powered AI system, limitations, and how it compares to its successor, the Figure 02, and competitors like the Unitree G1 and Tesla Optimus.
Key Takeaways
- The Figure 01 stands 5 feet 6 inches (1.68m) tall, weighs 132 lbs (60 kg), can carry 44 lbs (20 kg), and runs for approximately 5 hours on a single charge.
- Powered by OpenAI's vision-language models, Figure 01 can understand spoken instructions, describe what it sees, reason about tasks, and execute multi-step actions autonomously.
- Figure 01 was deployed at BMW's Spartanburg plant in South Carolina for manufacturing tasks, marking one of the first real-world factory deployments of a general-purpose humanoid.
- Figure AI has since launched the Figure 02 with upgraded specs (2.25 kWh battery, 16 DOF hands, 4th-gen AI), making the Figure 01 a first-generation platform that proved the concept.
- The Figure 01 is not available for individual purchase — it's deployed through enterprise partnerships. Estimated per-unit cost ranges from $30,000 to $150,000.
Figure 01 Full Specifications
Here's the complete spec sheet for the Figure 01 humanoid robot, verified against Figure AI's published data and third-party analyses:
| Specification | Figure 01 |
|---|---|
| Height | 1,680 mm (5'6" / 168 cm) |
| Weight | 60 kg (132 lbs) |
| Payload Capacity | 20 kg (44 lbs) |
| Walking Speed | 1.2 m/s (2.7 mph / 4.3 km/h) |
| Battery Life | ~5 hours operational |
| Degrees of Freedom | 40+ (full body) |
| Hands | Dexterous, multi-finger with force control |
| Actuators | Custom electric actuators |
| AI System | OpenAI vision-language model integration |
| Sensors | Cameras (stereo vision), microphones, IMU, force/torque sensors |
| Power | Fully electric |
| Operating Environment | Indoor industrial and commercial spaces |
At 5'6" and 132 lbs, the Figure 01 was designed to operate in spaces built for humans — standard doorways, aisles, staircases, and workstations. Its 44-lb payload capacity makes it suitable for manufacturing tasks like picking, placing, and carrying components. The 5-hour battery life was a standout feature in 2023–2024, exceeding most competitors at the time.
Figure 01 AI Capabilities: The OpenAI Integration
What separated the Figure 01 from every other humanoid robot in 2024 was its AI. Figure AI partnered with OpenAI to integrate advanced vision-language models directly into the robot's decision-making pipeline. The results were demonstrated in a viral March 2024 video that showed Figure 01:
- Conversing naturally: A human asked the robot what it could see on a table. Figure 01 correctly identified an apple, a plate, and a drying rack, then explained its reasoning.
- Planning multi-step tasks: When asked to give the human "something to eat," Figure 01 identified the apple as the only edible item and handed it over.
- Learning from observation: The robot learned to make coffee by watching a human perform the task once, then replicated the sequence autonomously.
- Real-time speech: Full-speed conversation with natural language understanding — not pre-scripted commands.
This wasn't teleoperation or pre-programmed behavior. The OpenAI model processed camera feeds and audio in real-time, generated a plan, and controlled the robot's body to execute it. Figure AI CEO Brett Adcock described it as "the first time a humanoid robot could truly reason about its environment and act on that reasoning."
The underlying system uses a vision-language-action (VLA) architecture — the same family of models pioneered by Google DeepMind's RT-2 and refined by Figure AI into their proprietary "Helix" system for the Figure 02.
Real-World Deployment: BMW Spartanburg
In January 2024, Figure AI announced a commercial agreement with BMW to deploy Figure 01 robots at BMW's Spartanburg manufacturing plant in South Carolina — one of BMW's largest global factories, producing over 1,500 vehicles per day.
The deployment started with specific manufacturing tasks:
- Sheet metal insertion: Figure 01 picked up body panel components and inserted them into fixtures — a repetitive, ergonomically challenging task.
- Material transport: Moving parts bins and components between workstations.
- Quality inspection support: Using its camera system to assist in visual quality checks.
BMW reported that on certain operations, the robot achieved task completion rates 400% faster than previous automated solutions. The deployment validated Figure AI's approach of building a general-purpose robot that learns tasks rather than requiring task-specific engineering.
This BMW partnership was a landmark moment for the humanoid robotics industry. It proved that a general-purpose humanoid could add value in a real automotive manufacturing environment — not just in controlled lab demos.
Figure 01 Design and Build Quality
The Figure 01's industrial design reflects its purpose as a commercial work tool rather than a research curiosity:
- Human-proportioned frame: At 5'6" and human-like proportions, Figure 01 works naturally at standard workstations, shelves, and equipment designed for human operators.
- Custom electric actuators: Every joint uses proprietary actuators designed for the torque, speed, and efficiency profiles needed for industrial tasks. No hydraulics — fully electric for cleaner, quieter operation.
- Dexterous hands: Multi-fingered hands with individual finger control and force sensing. Capable of grasping objects of varying sizes, from small fasteners to large parts bins.
- Modular architecture: Designed for field serviceability. Components can be swapped without returning the robot to the factory.
- Safety considerations: Rounded edges, compliant surfaces on contact points, and software-limited force output to enable human-proximate operation.
The robot's aesthetic is deliberately industrial — matte black and gray panels, exposed cable routing where necessary, and functional rather than decorative design. This is a tool, not a toy.
Figure 01 vs Figure 02: What Changed?
Figure AI launched the Figure 02 in mid-2024, building on everything learned from the Figure 01 deployment. Here's the direct comparison:
| Feature | Figure 01 | Figure 02 |
|---|---|---|
| Height | 1,680 mm (5'6") | 1,700 mm (5'7") |
| Weight | 60 kg (132 lbs) | 70 kg (154 lbs) |
| Payload | 20 kg (44 lbs) | 20 kg (44 lbs) |
| Battery | ~5 hours | 2.25 kWh, 5+ hours |
| Hand DOF | Multi-finger | 16 DOF per hand |
| AI System | OpenAI VLM (1st gen) | Helix (4th gen, proprietary) |
| Speech | Microphone + speaker | Enhanced onboard microphones + speakers |
| Cameras | Stereo vision | 6 RGB cameras, 360° coverage |
| Compute | External processing | 3 onboard AI inference chips |
| Walking Speed | 1.2 m/s | 1.2 m/s |
| Status | First-gen (limited deployment) | Active deployment at BMW + expanding |
The biggest upgrades from Figure 01 to Figure 02 are the hands (16 DOF per hand vs simpler grippers), the AI system (Helix is Figure's proprietary model, no longer dependent on OpenAI's API), and onboard compute (3 dedicated AI chips vs reliance on external processing). The Figure 02 is the production-ready version of the concept Figure 01 proved.
Figure 01 vs Competitors: How It Compares in 2026
The humanoid robot market has exploded since Figure 01's debut. Here's how it stacks up against the current field:
| Robot | Company | Height | Weight | Payload | Battery | Price | Available? |
|---|---|---|---|---|---|---|---|
| Figure 01 | Figure AI | 168 cm | 60 kg | 20 kg | ~5 hrs | $30K–$150K est. | ❌ Superseded by Figure 02 |
| Figure 02 | Figure AI | 170 cm | 70 kg | 20 kg | 5+ hrs | Enterprise only | ⚠️ BMW deployment |
| Unitree G1 | Unitree | 132 cm | 35 kg | 2–3 kg | ~2 hrs | $13,500+ | ✅ Ships globally |
| Tesla Optimus | Tesla | 173 cm | 57 kg | ~20 kg | Full shift | <$20K target | ❌ Internal testing |
| Apollo | Apptronik | 173 cm | 73 kg | 25 kg | ~4 hrs | Enterprise | ⚠️ Mercedes-Benz |
| Atlas (Electric) | Boston Dynamics | 150 cm | 89 kg | Heavy | — | Not for sale | ❌ Internal only |
| AgiBot A2 | AgiBot | 175 cm | 55 kg | 10 kg | ~2 hrs | Contact sales | ✅ 700+ shipped |
The Figure 01's key legacy is proving that a general-purpose humanoid could work in real factory conditions. While the hardware specs were competitive for 2023–2024, the AI integration was the real differentiator. By 2026, the Figure 02 has taken over as Figure AI's active platform, and competitors like AgiBot A2 (49 DOF, 200 TOPS AI) and Apptronik Apollo (25 kg payload, Mercedes deployment) have raised the bar.
For buyers looking for an affordable humanoid robot available today, the Unitree G1 starting at $13,500 is the most practical option. For enterprise manufacturing deployments, Figure 02 and Apollo lead the field.
Figure 01 Strengths and Weaknesses
Strengths
- ✅ Pioneered OpenAI-powered humanoid AI — first robot to demonstrate real conversational reasoning and autonomous task planning
- ✅ 5-hour battery life outperformed most competitors at launch
- ✅ 20 kg payload handles real manufacturing components
- ✅ Human-height form factor (5'6") works in standard human environments
- ✅ BMW deployment validated commercial viability in automotive manufacturing
- ✅ Fully electric — cleaner, quieter, and lower maintenance than hydraulic systems
- ✅ Modular design for field serviceability
- ✅ Task learning from observation — watch once, replicate autonomously
Weaknesses
- ❌ Not available for individual purchase — enterprise-only through Figure AI
- ❌ First-generation hardware superseded by Figure 02 with significantly better hands and AI
- ❌ Walking speed of 1.2 m/s is slower than Unitree H1 (3.3 m/s) or Tesla Optimus
- ❌ Limited hand dexterity compared to Figure 02's 16 DOF hands
- ❌ Relied on external compute for full AI capability — not fully edge-processed
- ❌ No public SDK or developer access — closed platform
- ❌ High estimated cost ($30K–$150K) compared to Unitree G1 ($13,500)
- ❌ Indoor industrial use only — no outdoor or rough terrain capability
Figure AI: Company Background and Funding
Understanding Figure 01 requires understanding Figure AI, one of the most well-funded robotics startups in history:
- Founded: 2022 by Brett Adcock (previously founded Archer Aviation, valued at $2.7B)
- Headquarters: Sunnyvale, California
- Total funding: Over $675 million as of early 2025
- Key investors: Microsoft, NVIDIA, OpenAI Startup Fund, Jeff Bezos (Bezos Expeditions), Parkway Venture Capital, Intel Capital
- Valuation: Approximately $2.6 billion (Series B, February 2024)
- Employees: 200+ engineers across AI, mechanical engineering, and robotics
- Production target: Figure AI plans to ship 100,000 humanoid robots over the next 4 years (announced January 2025, Forbes)
The funding level signals serious long-term commitment. With Microsoft and NVIDIA backing, Figure AI has access to cloud AI compute (Azure) and edge AI chips (NVIDIA) that smaller competitors cannot match. The 100,000-unit production target would make Figure AI one of the largest humanoid robot manufacturers in the world.
Who Is the Figure 01 For?
The Figure 01 is relevant for:
- Enterprise manufacturers evaluating humanoid robots for assembly, material handling, and logistics
- Robotics researchers studying the evolution of AI-powered humanoids
- Technology executives benchmarking humanoid capabilities for future adoption
- Investors tracking the humanoid robotics market trajectory
The Figure 01 is NOT for:
- Individual consumers or hobbyists — no retail availability
- Researchers needing open SDK access — the platform is closed
- Budget buyers — the Unitree G1 at $13,500 is the affordable option
- Home use — try the 1X NEO (in beta) or wait for Tesla Optimus
Figure 01 Timeline: From Concept to Deployment
Understanding the Figure 01's significance requires context of its rapid development:
- 2022: Figure AI founded by Brett Adcock. Company announces mission to build a general-purpose humanoid robot.
- March 2023: Figure 01 prototype revealed. First walking demos shown. Media attention surges.
- October 2023: Figure 01 demonstrated performing autonomous tasks — making coffee, sorting objects. OpenAI partnership announced.
- January 2024: BMW commercial agreement signed for Spartanburg plant deployment.
- February 2024: Series B funding at $2.6 billion valuation — $675M+ raised from Microsoft, NVIDIA, OpenAI, Jeff Bezos.
- March 2024: Viral demo video showing Figure 01 conversing with humans, reasoning about objects, and executing tasks autonomously via OpenAI integration.
- Mid-2024: Figure 02 launched with upgraded hardware. Figure 01 transitions to legacy status.
- January 2025: Figure AI announces plans to ship 100,000 humanoid robots over 4 years (Forbes). Figure 02 expands BMW deployment.
- 2026: Figure 02 is the active platform. Figure AI valued among the top humanoid robotics companies globally alongside Tesla, Boston Dynamics, and Unitree.
From founding to commercial factory deployment in under 2 years — Figure AI's pace was unprecedented in robotics. The Figure 01 was the vehicle that made it possible.
Our Verdict on the Figure 01
The Figure 01 was a historic product. It demonstrated that a general-purpose humanoid robot could understand language, reason about its environment, plan multi-step tasks, and execute them in a real factory — not just a research lab. The BMW deployment was proof that the concept works commercially.
However, by January 2026, the Figure 01 has been superseded by the Figure 02, which improves on every dimension: better hands (16 DOF), proprietary AI (Helix), onboard compute, and expanded deployment. The Figure 01 is best understood as the breakthrough prototype that launched Figure AI into the top tier of humanoid robotics companies.
For anyone looking to buy a humanoid robot today, the Figure 01/02 aren't options for individual purchase. The Unitree G1 starting at $13,500 is the most accessible humanoid you can actually buy and receive. For enterprise deployment, contact Figure AI directly or explore alternatives like the Apptronik Apollo or AgiBot A2.
Robozaps Rating: 7.8/10 — Groundbreaking AI integration on a capable platform, but superseded by Figure 02 and limited by enterprise-only availability.
Frequently Asked Questions About the Figure 01
What are the Figure 01 specs?
The Figure 01 stands 5'6" (168 cm), weighs 132 lbs (60 kg), carries up to 44 lbs (20 kg), walks at 2.7 mph (1.2 m/s), and operates for approximately 5 hours per charge. It has 40+ degrees of freedom and is powered by OpenAI's vision-language AI models.
How much does the Figure 01 cost?
The Figure 01 is not publicly priced. Industry estimates place it between $30,000 and $150,000 per unit for early enterprise deployments. It is not available for individual purchase — only through commercial partnerships with Figure AI.
Can you buy a Figure 01?
No. The Figure 01 is deployed exclusively through enterprise partnerships (e.g., BMW). Individual consumers cannot purchase one. For a humanoid robot you can actually buy today, see the most advanced humanoid robots for sale or the Unitree G1 starting at $13,500.
What is the difference between Figure 01 and Figure 02?
The Figure 02 improves on the Figure 01 with 16 DOF dexterous hands (vs simpler grippers), proprietary Helix AI (vs OpenAI integration), 3 onboard AI chips (vs external processing), 6 RGB cameras with 360° coverage, and a larger 2.25 kWh battery. The Figure 02 is the production-ready successor now deployed at BMW. Read our full Figure 02 review.
Is Figure 01 better than Tesla Optimus?
They target different markets. Figure 01 was deployed in real manufacturing before Optimus reached that stage. Optimus aims for mass-market pricing under $20,000, while Figure 01/02 targets enterprise. As of 2026, neither is available for public purchase. For a detailed comparison, see our Figure 01 vs Tesla Optimus analysis.
What AI does the Figure 01 use?
The Figure 01 uses OpenAI's vision-language model (VLM) for real-time perception, reasoning, and task planning. The robot processes camera feeds and audio through the AI model, which generates action plans executed by the robot's motor control system. The successor Figure 02 uses Figure AI's proprietary "Helix" AI system instead.
Where is the Figure 01 deployed?
The Figure 01 was deployed at BMW's Spartanburg manufacturing plant in South Carolina, USA. It performed tasks including sheet metal part insertion, material transport, and quality inspection support. BMW reported 400% faster task completion on certain operations.
How does Figure 01 compare to Unitree G1?
The Figure 01 is larger (168 cm vs 132 cm), heavier (60 kg vs 35 kg), and has a much higher payload (20 kg vs 2–3 kg). However, the Unitree G1 costs $13,500 and ships to anyone globally, while the Figure 01 is enterprise-only with estimated costs of $30K–$150K. For a full breakdown, see our Figure 01 vs Unitree G1 comparison.
